Smart Roller Shade Controller

Smart Roller Shade Controller

Smart Roller Shade Controller

FAQ
Please long-press the reset button for 5 seconds until the blue indicator light goes on,and then release it.
No, the motor can not be turned on/off manually after it powers off.
Please adjust the direction through "Adjust opening/closing direction of curtain" in "Settings" in the app.
Please long-press the Stop button "||" on the control box for 5 seconds until the blue indicator light goes on and then release it. When you hear the motor short beeps three times, the motor will return to normal status after it turns forward and backward once.
When the motor runs continuously for about 4 minutes, the motor will stop running and enter the overheating protection state. When the temperature returns to the appropriate level, it will work normally again (about 10-30 minutes to recover).
When the motor runs continuously for about 4 minutes, the motor will stop running and enter the overheating protection state. When the temperature returns to the appropriate level, it will work normally again (about 10-30 minutes to recover).
When the route of the motor is not set completely, the motor cannot be controlled through the app, and the homepage of the app will not display the control buttons. You need to complete the route settings according to the guideline, and then enter the app to control it.
The "dimming control" feature is suitable for Venetian blinds, Shangri-La blinds, gauze curtain, etc. You can use this feature to control the blade inclination angle of the Venetian blinds and Shangri-La blinds or set the overlapping area of two layers of gauze curtain to adjust indoor lighting.

Specifications

Product model

SRSC-M01

Rated voltage

220-230V~ 50Hz

Rated power

121W

Rated current

0.53 A

Executive standard

Q/QLML016

Operating temperature

-10℃~+40℃

Operating humidity

10%~95% RH, non-condensing

Pipe diameter

35mm

Rated torque

8N·m

Rated rotor speed

17 r/min

Wireless connection

Zigbee

Working system

S2 4min

Zigbee Operation Frequency

2405-2480 MHz

Zigbee Maximum Output Power

≤13 dBm
